主要應用

高能二管泵浦，全固態(tài)，　Q-SWITCHEDLASER

高能二管泵浦固體，　q開關激光在532 nm的特性

　單脈沖能量高、短脈沖，時間和峰值功率高,

　廣泛用于PIV、生活,庫,icp，科學研究、激光加工、軍事、等等。

產品特點

用于透明固體物質LIBS光譜檢測的激光器。具有窄脈寬、高單脈沖能量等特點。

窄脈寬、高能量，可以有效擊穿各類氣體，適用于氣體及液體樣品LIBS光譜檢測

1064 LIBS激光器

（100MJ-1000MJ）

NBET-L-1064/350~1000mJ\

HIGH ENERGY LAMP PUMPED SOLID STATE Q-SWITCHED LASER

High energy lamp pumped solid state Q-switched laser at 1064nm has the

features of high single pulse energy ， short pulse duration，and high peak

power，which is widely used in PIV, LIF, LIBS, ICP-MS, Raman，scientific research,

military ,and so on

技術參數(shù)

Wavelength (nm)      1064±1

Operating mode Q-switched: EOM (Electro-optic modulation)

Single pulse energy (mJ    350   500   700   1000

Pulse duration (ns)        <10 <10 <8 <8

Rep. rate (Hz) 1~10 (adjustable)

Energy stability<3%

Beam divergence, full angle (mrad) ~1 ~1 ~1 ~3

Beam diameter (mm)  7  8   8   9

Warm-up time (minutes) <15

Beam height from base plate (mm)80

Operating temperature (℃) 15~35

Power supply (220/110VAC) PSU-NBET-A(3U)

Expected lifetime of lamp (pulses) 107~108

Warranty period 1 year

Available Options SHG Module ;Higher Repetition Rates:≤20Hz ; Jitter:~1ns（Sdev）
